MCR 40 Mini Crane | Diesel & Electric Motor Configurations

TECHNICAL SPECIFICATIONS		STD
A	m	0,79
B	m	2,54
C	m	1,09
D	m	1,25
H	m	1,93
a1	°	25
a2	°	-
X	m	4,7
Y	m	4,66
X1	m	5,55
Y1	m	0,62
Y2	m	6,33
Crane maximum moment	Tm	4,0
Maximum horizontal working radius	m	6,1
Maximum movable load	kg	2100
Crane arm working angle	°	± 80
Crane rotation angle	°	340
Rotation torque	kNm	3,2
Maximum speed of movement	km/h	2,5
Maximum slope capacity	°	25
Maximum operational pressure	bar	200
Maximum capacity crane distributor	l/min	8
Oil reservoir capacity	l	22
Single winch reach (optional)	kg cable	800 ⌀7mm - 46m

WEIGHTS		STD	E
Standard machine weight	kg	1460	1500
Track ground pressure	kg/cm²	0,37	0,38
Maximum load on stabiliser foot	kg	1700

MCR 40
